Redundant Wall Mounted Air Conditioner

The ULTIMAte environmental control system. Single package, 100% redundant, wall mounted, & purpose- built for use in industrial and/or hazardous (classified) applications

STANDARD FEATURES:

• *Certified by Intertek® (bearing the ETL mark) for compliance to applicable codes and standards
• 100% redundant operation
• Corrosion resistant coatings for refrigerant coils and tubing
• Built-in controls throat for operational control of system
• Built-in system and environment alarm contacts
• Dual PLC control with touchscreens for ease of use
• Spark resistant fan and blower construction
• Totally Enclosed Fan-Cooled (TEFC) motors
• EPA approved HFC type refrigerants
• Stainless type 304 cabinet and chassis
• Fully serviceable from access panels and external grilles

OPTIONS:

• Integral Siemens LOGO! PLC in lieu of touchscreen PLC
• Redundant nominal cooling from dual 4 tons to dual 30 tons
• Electric heat (limited by temperature code and system size)
• Stainless steel type 316 cabinet and chassis for added corrosion protection in offshore applications
• Three phase operation in 60 or 50 Hz applications
• Configurable for operation in various non-hazardous and hazardous rated locations
• Protective component coatings for prolonged life in corrosive environments
• NFPA 496, Type Z package for automatic control of positive pressure and purge air flow for the space
• Advanced chemical filtration packages
• Blast/fire damper accommodations for hazard prone applications
• Low/High ambient packages for operation in extreme environments

APPLICATIONS:

• Offshore HVAC
• Control rooms, driller’s cabins, living quarters, and other manned applications
• MCC, RIE, power, and various other buildings



*Certification may not apply to all configurations. Please contact our technical sales department for more information.
